Cargo Golf Carts,4 Passengers Golf Cart Street tire
Item No: SC-401B-C,48V/5000W
MOQ: 1
Contact Us To Start Customizing Now
Description
| Electronic System | Controller | JC/Curtis/ HS Toyota Cooperated Brand 48V/350A |
| Battery | Lithium Battery48V108Ah SCRN48V108L | |
| Motor | JC/Mahle/ HS Motor Toyota Cooperated 48V/5000W | |
| Charger | On-board input 110V-240V, output 48V/25A | |
| Vehicle Body | Windshield | 3-C passed armoured glass OR DOT passed PVC foldable windshield |
| Roof | longer and stroger, injection molded ABS | |
| Seats | High density sponge,thickening leather and high qualited arm rest | |
| Side Board | aluminum alloy with antiskid finishing | |
| Floor Mat | skid-proof full piece ruber floor mat | |
| Roof holder | made with iron steel material and finished with water proof coating | |
| Dashboard | Touch screen,Include battery meter, blue-tooth MP3 player, USB charger sockets and switches,camera | |
| View mirror | two side mirrors and one inside mirror | |
| Tire and Rim | 215/35-12 street tire | |
| Lights and Signal | Front and rear lights,Turning lights, Brake lights, electrical horn | |
| Chassis | Frame | Made with Q23 high quality iron steel and finished with galvanize coating |
| Steering System | Self Compensating Rack & Pinion Steering | |
| Brake System | 4 wheels hydralic brake ( front disc brake and rear drum brake)+pedal parking | |
| Suspension | Leaf spring and hydraulic damper | |
| Driving System | Rear two wheels driving | |
| Rear Axle | speed ratio 12.25:1 | |
| Stepboard | optional （steel frame with Aluminium surfave anti skid plate） |
Detailed Parameters
| Passengers | 2 | |
| Voltage | 48 | |
| Controller | 48V/350A | |
| Motor Power (W) | 5KW | |
| Battery (V/AH) | 48V/108AH | |
| Charging Time (H) | 8~10 | |
| Size (mm) | 3200x1150x1870 | |
| Cargo Size (mm) | 2000*1100*300 | |
| Wheelbase (mm) | 2440 | |
| Wheel Tread (front/rear mm) | 960/980 | |
| Driving Range (full load km) | 80 | |
| Maximum Speed (KM/H) | 25~45 | |
| Mini Braking Distance (M) | ≤3 | |
| Mini Turning Radius(M) | ≤5.5 | |
| Max Gradability (full load) | 20% | |
| Net Weight （KG) | 460 | |
| Gross Weight ( KG) | 530 | |
| Mini Ground Clearance | 150 | |
| Wheel (inch) | 12 | |
| Tire | 215/35-12 | |
| Brake System | Hydraulic front disc rear drum | |
| Color Options | Body and Seat can be customized according to Request(Subject to our Approval) | |
| 2pcs of Charging Port | |
| 4pcs of Cup Holder | |
| Bluetooth 、Radio、camera、phone link.. | |
| Battery capacity power meter , speed meter |
